named as “UP” and is named as “DOWN”.
3. Note for Users
Be care of the safety use. Don’t attempt to release the connector when battery is on power.
Try to avoid hitting.
Don’t split the waterproof sticker to avoid affecting the waterproof performance.
Don’t modify system parameters to avoid parameters disorder.
Make the display repaired when error code appears.
4. Installation Instruction
When the e-bike is powered off, you can insert the connector of display and the corresponding
connector of controller to complete the installation, and adjust the display to a suitable angle.
5. User Settings
5.1#On#/#Off#
Long press “MODE” button then the display will work normally, and the controller will power on at the
same time.
With the display on, long press “MODE” button, the display will shut down, the display will leave off
battery, the leakage current of display on is less than 1μA.
If the e-bike is not used for more than 10 minutes, the display will automatically shut
down.
5.2#User#interface#
There are two display interfaces, including normal display interface and data statistics interface. Long
