Clearances – MDV31 – Mantels & Surrounds
Clearance to Combustibles
mm251/ sehcni 6 )tinu fo( kcaB
mm251/ sehcni 6 )gnimarf ni tinu fo( sediS
mm52/ hcni 1 epiP lacitreV
mm0/ sehcni 0 )sffodnats morf( kcaB
mm0/ sehcni 0 )sffodnats morf( ediS
mm0/ sehcni 0 roolF
Ceiling (from bottom of fireplace) 60 inches
/152.4cm
mm46 / sehcni 5.2 epiP latnoziroH fo poT
Top Framing from Standoff 0 inches /0mm
Louvered Units Only
Top of 90° Bend No Sleeve, in Enclosure over
52”
4 inches /102mm
Bottom of Top Enclosure with Insulation
Sleeve
42 inches
/1067mm
In Low Profile Enclosures from 42” to 52”
Top of Horizontal Pipe in Enclosure without
Sleeve
12 inches /305mm
Top of Horizontal Pipe in Low Profile
Enclosure with Insulation Sleeve
2 inches 51mm
MDV31 With Clean View Kit
Top of 90° Bend No Sleeve, in enclosure over
81”
4 inches /102mm
Bottom of Top Enclosure with Insulation
Sleeve
60 inches
/152.4cm
Top of Horizontal Pipe in Enclosure with
insulation Sleeve
4 inches /102cm
