29
REMOVAL OF METAL PANEL BEFORE INSTALLING REAR BRICK PANEL
1. Locate 2 screws on bottom rear of unit holding metal panel to firebox bottom, remove the 2 screws and discard.
2. Hold metal panel by the bottom and pull forward and down at the same time. This will release the panel from the holder at
the top of the unit. Discard metal panel.
3. The brick panel can now be installed. (See installation of brick on page 16 of Manual.)
OPTIONAL BACK AND SIDE BRICK PANEL INSTALLATIONS
1. Remove side brick clip located on top of firebox.
2. Slide side brick panel into firebox through the small side
opening and center from left to right and push tight
against side wall of firebox.
3. Place brick clip back into position and tighten.
1. Remove back brick clip located on top of firebox.
2. Slide back brick panel into firebox through the large side
opening and center from left to right and push tight
against side wall of firebox.
3. Place brick clip back into position and tighten.
Brick Panel Installation
