Kipor IG1000 Shop Manual

3.7 Smart system doesn’t work with zero load or engine speed doesn’t increase with Smart
system on and load connected.
Check the AC output
Perform the generator
troubleshooting following the
section on “No AC or low voltage”
Abnormal
Normal
Check the throttle control motor
Replace the throttle control motor
Abnormal
Normal
Check the Smart Throttle switch
Check Smart switch connection wire
Repair or replace the wire harness
Abnormal
Normal
Normal
Replace the smart Throttle switch
Abnormal
Replace the inverter unit
3.8 No or low AC output
Disconnect the load, and restart the
engine
ON
Is the overload indicator light ON?
OFF
Is the engine speed normal?
Smart switch
ON: 4200±100rpm
OFF:5500±100rpm
Abnormal
Perform the throttle control system
test
Normal
Abnormal
Stop the engine and check the AC
receptacle
Replace the AC receptacle
Normal
Disconnect the main winding and sub
winding (CG) 6p connector on inverte
r
unit. Start the generator and measure
the voltage between pins 1&4, 2&4, 1&2.
Each reading should be at least 290
volts.
1. Check and repair stator wiring
harness or replace stator
2. Check rotor magnetism. If
decreasing, replace the rotor
Abnormal
Normal
17
Replace the inverter unit
© 2011 Kipor Power Systems, Inc.
