1. SPECIFICATIONS and WIRING DIAGRAM
1.1 SPECIFICATIONS
Dimensions and weights
Model IG1000/IG1000P
Overall Length in (mm) 18.1 (460)
Overall Width in (mm) 9.8 (248)
Overall Height in (mm) 15.6 (395)
Net Weight in (Kg) 30.8 (14)
Engine
Model KG144
Type 4-stroke,OHV, single cylinder, Gasoline engine
Displacement cu in. (cc) 3.3 (53.5)
Maximum horsepower/rpm 1.3/5500
Compression ratio 8.5:1
Cooling system Forced air-cooled
Ignition system T.C.I
Ignition timing 29°B.T.D.C
Spark plug UR5
Carburetor Float type, Horizontal, butterfly valve type
Air cleaner Semi-dry type
Governor Electronic control
Lubrication system Forced splash
Oil capacity qt (L) .19 (0.22)
Starting system Recoil starter
Stopping system Primary circuit ground
Fuel Automotive unleaded gasoline 87 octane
Alternator
Model KD10
Generator type Multi pole rotation
Generator structure Self-ventilation drip-proof alternator
Excitation Self-excitation (Magnet type)
Voltage regulation system Plush width modulation
Phase Three phase
Rotating direction Clockwise (Viewed from the generator)
Frequency regulation AC-DC-AC conversion
