Kipor IG1000 - No DC Output

3.9 No DC output
Normal
Abnormal
Check the engine speed
Abnormal
Perform the throttle control system
troubleshooting
Normal Abnormal
Replace the DC receptacle Check the DC receptacle
Normal
Check the rectifier
Abnormal
Replace the fuse Check the 5 amp fuse
Normal
Normal
The rotor loses excitation,
replace the rotor
Measure the resistance
between the two blue wires
on the rectifier.
Abnormal
Check and repair the wiring
harness or replace the
stator
Resistance: 0.16-0.20Ω
Replace the rectifier
