Performance
Model IG1000
Maximum output AC 1.0KVA
Rated output AC 0.9KVA
Rated output DC 100W
Rated frequency 60HZ
Rated voltage AC 120V
Rated voltage DC 12V
Rated current AC 7.5A
Rated current DC 8.3A
Power factor 1.0
Voltage variation rate Momentary
Average
Average time
10%max.
1.5%max.
3 sec. max.
Voltage stability ±1%
Frequency variation rate Momentary
Average
Average time
1%max.
1%max.
1 sec. max.
Frequency stability ±0.1%
Insulation resistance 10MΩ min.
AC circuit protector 8.8 A
DC circuit protector 10 A
Fuel tank capacity-gal (L) .69 (2.6)
Operating hours 4
Noise level NL-FL @ 23’ (7 m) 60-65 dB
