Kirby Avalir G10E Sentria User Manual

3332
5
Turn the Multi-Surface Shampoo System over and pull up on
the Belt to loosen and remove the Rotary Mop.
6
Slide the Belt from the Multi-Surface Shampoo System over
the center of the carpet brush roll and insert it into the Multi-
Surface Shampoo System.
7
Turn the Multi-Surface Shampoo System over. While pushing
up on the belt with your finger, use the handle on the Belt
Lifter to turn it counterclockwise until the red arrows line up.
The Belt Lifter Hook will catch and stretch the belt.
8
Check to make sure that the baffle strip is in place on the
bottom of the Multi-Surface Shampoo System. Insert the
baffle strip if necessary with flat side facing the brush roll.
NOTICE Property Damage Risk. Make sure the baffle strip
is in place on the Multi-Surface Shampoo System before
using on carpet. Failure to do so may result in property
damage.
9
Press the Toe-Touch Control Bottom Pedal all the way down
to raise the front of the unit.
