53
MAINTENANCE
ALWAYS turn off the unit and unplug it from the wall outlet
prior to doing any maintenance.
Changing the Power Nozzle Belt
1
After removing the Power Nozzle, turn the Belt Lifter clock-
wise until the green arrows line up.
2
Unlock the Rug Plate by unhooking the two latches on the
rear of the Power Nozzle. Pull on the rear edge of the Rug
Plate to remove.
3
Note the bristle height setting which is marked on the end of
the Brush Roll before lifting out the Brush Roll. See page 55.
4
Slide off the old belt and replace with a new one.
