Kirisun DP480 Service Manual

DP480 Service Manual
62
to 125℃
12
121D03000006
rectifier diode
ROHM,RB706UM-40,
1
D30
13
2RS1-16-000O
R chip resistor
yageo,RC0603JR-070RL,0,Ω,±
5%,1608
1
FB105
14
121I04000023
linear IC
韦尔,WS72321B-5/TR,SOT353,-40
to +125℃,
1
IC6
15
2RS1-10-103J
R chip resistor
yageo,RC0402JR-0710KL,10,KΩ,
±5%,0402
6
R1,R12,R15,R16,R17,R18
16
2RS1-10-102J
R chip resistor
yageo,RC0402JR-071KL,1KΩ,±
5%,0402
3
R3,R7,R8
17
2RS1-10-000O
R chip resistor
yageo,RC0402JR-070RL,0,Ω,±
5%,0402
2
R4,R68
18
2RS1-10-101J
R chip resistor
yageo,RC0402JR-07100RL,100,
Ω,±5%,0402
3
R5,R6,R19
19
2RS1-10-511J
R chip resistor
yageo,RC0402JR-07510RL,510,
Ω,±5%,0402
2
R13,R14
20
2RS1-06-103J
chip resistor
yageo,RC0201JR-0710KL,10,KΩ,
±5%,0201
5
R20,R21,R27,R2,R11
21
2RS1-06-473J
chip resistor
yageo,RC0201JR-0747KL,47,KΩ,
±5%,0201
3
R326,R332,R333
22
2RS1-06-102J
chip resistor
yageo,RC0201JR-071KL,1,KΩ,±
5%,0201
3
R328,R329,R133
23
2RS1-06-104J
chip resistor
yageo,RC0201JR-07100KL,100K
Ω,±5%,0201,
2
R330,R331
