Kirisun DP480 Service Manual

DP480 Service Manual
63
24
1IS1-LN1121P332MR
SMD voltage regulator IC
Natlinear,LN1121P332MR,SOT23-
3,-40 to +85℃
3
U1,U3,U4
25
121I02000005
Storage IC
W25Q64JVZEIQ,2.7-3.6V,
1
U0005
26
121I01000003
MCU+baseband IC
HS8861;175;TFBGA;7.8X7.8;040;
BB,
1
U2100
27
5OT1-26R0-
DSB221SDN
Temperature
compensated crystal
oscillator
KDS,1XXB26000MAA,26MHz±
0.5ppm,2520
1
X2
28
136P04000077
PCB
DP405W_MODULE,36.4X24.7mm,
4-layer,1.0mm
1
29
1DS1-1SS390
SMD switch diode
ROHM,1SS390,1.6mm*0.8mm*0.6
mm,-55℃ to 125℃
1
D105
30
2CC1-10-C0G500-
7R0C
multi-layer chip
capacitor
MURATA,GRM1555C1H7R0CA01
D,7,pF,±0.25pF,50V,0402,C0G
2
C14,C19
31
2CC1-10-X7R500-
103K
R multi-layer chip
capacitor
MURATA,GRM155R71H103KA88
D,10,nF,±10%,50V,0402,X7R
3
C2,C5,C16
Table 4 Material List of Key PCB
SN
Material NO.
Material Name
Specification
QTY
Position
1
2CC1-10-C0G500-
101J
R multi-layer chip
capacitor
1005,100P±5%,50V,C0G
8
C5,C6,C7,C8,C9,C10,C11,C12
2
2CC1-10-X7R160-
104K
R multi-layer chip
capacitor
1005,100nF±10%,16V,X7R
8
C1,C2,C3,C4,C13,C14,C15,C16
3
3CF1-BL112-30RU
SMD FFC/FPC
connector
Spacing 0.5 mm, 30-pin,
horizontal type
1
J1
