DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
13
1DZ1-PESD12VS1U
B
SMD voltage regulator
diode
PESD12VS1UB, lead free 1 D2
14 1DR1-1SR154-400 R SMD rectifier diode 1SR154-400, 4532 1 D3
15 3FW1-42932-302320 R SMD fuse
(SC) 429003/433003/466003,
3216, 3A/32V
1 F1
16 5FE1-BLM11A601S R SMD EMI filter
1608,
BLM11A601S/BLM18AG601S
(0138-05)
7 FB1,FB4,FB11,L68,L69,L70,L71
17 5FE1-CB100505-102 SMD EMI filter 1005, 1KΩ [Made in China] 31
FB38,FB39,FB40,FB17,FB20,FB41,FB47,FB48,FB3,FB44,FB
45,FB5,FB6,FB7,FB8,FB9,FB10,R38,FB13,FB14,FB15,FB18,
FB46,R222,R246,R254,R255,R256,R271,R272,R273
18 1IS1-MP2359
SMD switch power supply
IC
MP2359, 6PIN, 1.2A 24V,
1.4MHz, TSOT-23-6
1 IC1
19
1IS1-XC6209B552M
R
SMD voltage regulator IC 5.5V, SOT-23-5 encapsulation 1 IC3
20 1IS1-XC6209F502PR
SMD voltage regulator IC
XC6209F502PR, SOT-89-5,
5.0V
1 IC24
21 2LW1-35UF-472KB SMD wire wound inductor
3.5*3.0*2.1, 4.7UH±20%,
PIO32-4R7MT, lead free
2 L64,L65
22 1TF1-ST2301
R SMD field effect
transistor
ST2301A, SOT-23 5 Q17,Q23,Q102,Q29,Q26
23 1TT1-DTC144EE R SMD triode
Digital triode, DTC144EE (26),
SOT323
9 Q22,Q24,Q25,Q2,Q18,Q19,Q20,Q21,Q27
48
