Kirisun DP580 Service Manual

DP580 Service Manual
Pin NO.
Port NO.
Net Label
Description
U19
GPIO_D13
KC_R3
Key pad
V17
GPIO_D100
KEYPAD_BL
Backlight of key pad
H5
USB_DM
USB_DM
USB port
J5
USB_DP
USB_DP
USB port
L1
HPL_OUT
MODE1
Output of crystal modulation
M1
HPR_OUT
MODE2
Output of VCO modulation
IC22
VOUTB
APC
Tx power control
IC22 VOUTA RXTV Receiving band-pass control
E2
HP_MICN
AFADC
Demodulated signal input
J19/IC2.AI
N1
BSENS SQL Signal quality detection
L22/IC2.AI
N2
ADCIN RSSI Field intensity detection
IC2.AIN3
MANDOWN
MANDOWN
Man Down detection
IC2.AIN0 BATDET BATDET Battery voltage detection
P6---F17
PRST---RSTOUTB
PRST
F16---E15
OSCEN--PMU_OSCEN
OSCEN
E11
GPIO_D44
SECRET_RST
Reset encryption chip
K18
CLKOUT2/GPIO_D107
SECRET_CLK
Clock of encryption chip
B12
GPIO_D45
SECRET_DATA
Encryption chip data
5.Feature Description and Parameter Setting
5.1.Stun, Revive and Remote Monitor
Stun
You can enable this function, so that the radio can be stunned after receiving a Stun command. A stunned
radio can only receive a Revive command but cannot send or receive other signals.
Revive
You can enable this function, so that a stunned radio can be revived after receiving a Revive command.
After the radio is revived, it can operate normally again.
Remote Monitor
When the radio receives Remote Monitor command, it will automatically turn on the transmitting and the
monitoring party can listen to the surroundings around the monitored radio.
13
