Kirisun DP580 Service Manual

DP580 Service Manual
Pin NO.
Port NO.
Net Label
Description
T18 GPIO_D109 MICSELECT
Switch to internal/external microphone
(external at high level)
AA15 GPIO_D30/D93 PASELECT
Switch to internal/external speaker
(external at high level)
AC16 GPIO_D110 MUTE Speaker mute (mute at low level)
AC21
LCD_D0
LCD_D0
Data 0 of parallel interfaced LCD
AC20
LCD_D1
LCD_D1
Data 1 of parallel interfaced LCD
W22
LCD_D2
LCD_D2
Data 2 of parallel interfaced LCD
AA22
LCD_D3
LCD_D3
Data 3 of parallel interfaced LCD
AC22
LCD_D4
LCD_D4
Data 4 of parallel interfaced LCD
AB23
LCD_D5
LCD_D5
Data 5 of parallel interfaced LCD
Y22
LCD_D6
LCD_D6
Data 6 of parallel interfaced LCD
AC23
LCD_D7
LCD_D7
Data 7 of parallel interfaced LCD
AB22
LCD_RD
LCD_RD
Allow LCD operation
AB20 LCD_WR LCD_WR LCD read/write control
AB21
LCD_CS
LCD_CS
Chip select of LCD
AB19
GPIO_D15
LCD_RST
Reset LCD
V14
LCD_RS
LCD_RS
LCD command data
M21
GPIO_D27
SLCD_RS
Data command of serial LCD
C9
GPIO_D105
LCD_BL
LCD backlight
R21
SSI0_CLK
SSI0_CLK
Serial LCD clock
N21
SSI0_CS0
SSI0_CS0
Serial LCD clock
P21
SSI0_DATAOUT
SSI0_DATAOUT
Serial LCD data
W14
GPIO_D101
E2_WP
E2 write protection
C17
I2C_SCL
I2C_SCL
I2C clock (E2, ADC)
C18
I2C_DATA
I2C_DATA
I2C data (E3, ADC)
AC15
GPIO_D92
ADC_RDY
ADC ready
F6
GPIO_D111
BT_ENABLE
Bluetooth module power switch
F5
GPIO_D112
BT_RST
Reset Bluetooth module
F11 GPIO2
MANDOWNPO
WERC
Power switch of Man Down (on at high
level)
V19
GPIO_D96
KB_C0
Key pad
T21 GPIO_D97 KB_C1 Key pad
U18
GPIO_D98
KB_C2
Key pad
V16
GPIO_D99
KB_C3
Key pad
V22
GPIO_D10
KC_R0
Key pad
V15
GPIO_D11
KC_R1
Key pad
U21
GPIO_D12
KC_R2
Key pad
12
