DP580 Service Manual
Pin NO.
Port NO.
Net Label
Description
level)
E12 GPIO_D50 TXENABLE
Enable transmitting power amplification
(valid at high level)
AB16
GPIO_D104 GPSENABLE
Enable GPS receiving (valid at high
level)
H18
RXD1
RXD1
Output GPS module data
J18
TXD1
TXD1
Input GPS module data
J14
RXD0
RXD0
Output BT chip data
J15
TXD0
TXD0
Input BT chip data
F9
GPIO_D54
TXRX
Select TX/RX VCO (RX at high level)
B10 GPIO_D56 SPI_DATA
SPI data (phase-locked loop, IF chip,
DAC)
B11 GPIO_D57 SPI_CLK
SPI clock (phase-locked loop, IF chip,
DAC)
C11 GPIO_D55 72310_LD Phase-locked loop lock detection
A10
GPIO_D58
SPI_72310_CS
Chip select of phase-locked loop
C14
GPIO_D51
2365_PDN
Power saving mode of IF chip
E14 GPIO_D49 2365_RSTN Reset IF chip
C12
GPIO_D53
SPI_2365_CS
Chip select of IF chip
C13
GPIO_D52
SPI_DAC_CS
Chip select of DAC
T19
GPIO_D14
PTT
PTT key input
V13
GPIO_D102
ONEWIRE
1-wire bus
B8
GPIO_D16
EX_PTT
Input from PTT key
F10
GPIO_D0
TOPKEY
Input from top key
E10 GPIO_D3 SIDEKEY0 Input 0 via side key
F13
GPIO_D1
SIDEKEY1
Input 1 via side key
A7
GPIO_D19
DPTA_SEL0
Accessory detection 0
B7
GPIO_D20
DPTA_SEL1
Accessory detection 1
C7
GPIO_D17
RED_LED
Enable red indicator
A8
GPIO_D18
GREEN_LED
Enable green indicator
B9
GPIO_D21
CH_ENC0
Switch of channel encoding
AA18
GPIO_D22
CH_ENC1
Switch of channel encoding
AB17
GPIO_D23
CH_ENC2
Switch of channel encoding
AA17
GPIO_D24
CH_ENC3
Switch of channel encoding
R14 GPIO_D6 AUDIO_ENC0 Switch of channel encoding
W13
GPIO_D7
AUDIO_ENC1
Switch of channel encoding
F15
GPIO_D8
AUDIO_ENC2
Switch of channel encoding
F14
GPIO_D9
AUDIO_ENC3
Switch of channel encoding
11
