11
7MHR-4002-16A-W9
DP770 Knob waterproof pad silica gel; black
1
12 4SS7-3525-016-100A
DP770 speaker（waterproof）Φ=35mm，H=25mm，16Ω，
1W
1
13
4SM7-4002-A40
Waterproof microphone with cover Φ7.0mm, height 2.8mm,
1
14
4SM7-4002-A40
Encoder switch RE11(Linjiwei)
1
15 7MHR-4002-09A-W9
DP770 The silicone number buttons；
PT432C/ character
with photopermeability
1
16 7MHS-4002-01A-W DP770 LCD Cupronickel stents; Xianfeng Hardware 1
17 7MHC-4002-11A-W
DP770 display shielding cover 44.3*34.1*2.0MM,
cupronickel
1
18 4PC7-4002H-A LCD display ZYW-T18CP-20PJ-B 1
19 7MHS-4002-03A-W
Numeric key METAL DOME diameter 4.0；SUS301
1
20 6PM7-4002-HKG DP770KEY-LCD PCB Four-layer board 1
21
7SMF-020040M-SZYB-N
M2*4 iron hardened tooth machine cross screw, Nylok
7
22 7GCM-180090015-J
DP770 main board double-sided adhesive foam black foam
18*9*1.5
1
23 7GCM-100090015-J
LCD Socket black foam double-
sided adhesive
foam10*9*1.5
2
24
7SMF-026060M-SZHT-B
1
M2.6*6 cross, machine ferrous hardened, Black zinc
machine teeth
2
25
6SS3-BJ4026-A
KBJ-15 Belt Clip PC+ABS
1
26
7MHR-4002-11A-W9
DP770 main waterproof circle of silica gel; black
1
27 6SS3-DC7198-A KB-77B battery 1
28 7MHM-4002-02-W Aluminum chasis Poron , liner, Poron 36.5*2.5*1.0 1
29
7SAF-020110M-SZYB-Z
1
2.0X11.0 tooth machine cross screws 5.3 harden iron; zinc
plating-black
2
30 7MHR-4002-19A-W9 DP770 Screw waterproof rubber ring; black;polished 4
31 7GCB-070045005-J
Φ7 Microphone protection water perforated film with plastic
mesh
2
32
7MHP-4002-05A-W9
DP770 main unit top cover PC+ABS; texture; black
1
33
7MHL-4002-01-W
DP770 aluminum chasis ADC12; burnished
1
34
7MHR-7042-06B-W0
thermally conductive pad, black,3*6*9mm
1
35 3CR7-SMA-50JF-4 Antenna connector SMA-J, Flange installation 1
36 7MHR-4002-15A-W9 DP770 antenna connector Waterproof pad silicone;black 1
37 4MV3-KFF081522 φ8Dc motor vibration KFF081522 1
38 7MHR-4002-17A-W9 DP770 Motor silicone pad silica gel; black 1
39 7MHS-4002-02A-W
DP770 Motor pressure pieces of stainless steel; natural
color; Junyu, lead free
1
40 7MHR-4002-18A-W9 DP770 Discharge seating silicone; black 1
41 7MHP-4002-01A-W TD7700 battery connector BC-2P-41PH-6.8H 1
42 7MHC-4002-02A-W
DP770 shielding cover holder 一 43.4*32.3mm; cupronickel
1
43 7MBM-S4002-A EMI Gasket 12*7*7 With double-sided adhesive 3
44 7MHC-4002-16A-W1 GPS shielding cover base, cupronickel; Junyu; Lead free 1
45
7MHC-4002-04A-W
DP770shielding cover holder 22.8*15.6mm; cupronickel
1
46
6PM7-4002-HMH
DP770-02 main board PCB ten-layer board
1
