Kirisun DP770 Service Manual

DP770 Service Manual
Appendix 1 Material List（Electrics Parts）400-470MHz
NO. Part Number Name Quantity Position Mark
1 6SS2-4002B-HMD
DP770 Main Board suite（BD+GPS）
1
2 6SS1-4002B-HMC
DP770-02 main board SMD suite
（
BD+GPS
）
1
3 0SS1-4002B-HME
DP770-02
main board SMD
units(BD+GPS)
1
4
1DR1-1SR154-400
R SMD commutation diode
1
D903
5 1DS1-DA2S10100L R SMD switch diode 9
D110,D111,D113,D701,D702，D703，D704,D15,D506
6 1DS1-DAN222 R SMD switch diode 1 D904
7 1DS1-HSC277 R SMD switch diode 1 D112
8 1DS1-HVC131 R SMD switch diode 4
D301,D302，D303，D304
9 1DV1-1SV278 R SMD varactor 1 D109
10 1DV1-1SV305 R SMD varactor 1 D201
11 1DV1-HVC350B R SMD varactor 4 D103,D104,D107,D108
12
1DV1-HVC376B
R SMD varactor
9
D101,D102,D105,D106,D202,D203
，
D204
，
D205
，
D206
13
1DZ1-MMSZ4678T1
G
SMD voltage regulated diode 1 D905
14
1DZ1-PESD12VS1U
B
SMD voltage regulated diode 2 D901,D902
15
1DZ1-PESD3V3S1U
B
SMD voltage regulated diode 1 D907
16 1DZ1-PESD5V0S1U
SMD voltage regulated diodeDP770
，
1 D906
Page 36 of 102
