Kirisun DP770 Service Manual

DP770 Service Manual
7. Main Specifications
General Specifications
Frequency
UHF1: 400-470MHz, VHF: 136-174MHz
Channel Capacity
1024
Channel Spacing
12.5kHz/20kHz/25kHz
Weight
362g（with battery and antenna)
Dimension
138mm*62mm*38mm
Display
1.8 Inches 65535 Color Display
Battery Capacity
7.4V 2000mAH Li-ion
Working Time（5-5-90）
Analog: 13.5 Hours
Digital: 15 Hours
Environmental Operating Conditions
Working Temperature
-30
℃
~+60
℃
Storage Temperature
-40
℃
~+85
℃
Waterproof/Dustproof
IP67
Electrostatic Defending
IEC 61000-4-2（Level 4）
±8kV （Touch）
±15kV （Air）
MILST
MIL-STD-810 C/D/E/F/G
Humidity
MIL-STD-810 C/D/E/F/G
Shock and Vibration
MIL-STD-810 C/D/E/F/G
Receiver Part
Frequency Stability
±1.5ppm
Analog Sensitivity
0.3uV（12dB SINAD）/0.22uV（12dB SINAD，Typical）
Page 31 of 102
