Kirisun DP770 Service Manual

DP770 Service Manual
6
229 7MHC-4002-02A-W
DP770 shield cover
bracket 1
1 S1
230 7MHC-4002-04A-W
DP770 shield cover
bracket 2
1 S2
231 7MHC-4002-16A-W1 GPS shield cover base 1 1 S3
232 6PM7-4070-HMC
DP770-01mainboard
PCB
1
233 7PLJ-025006-T01A
High temperature sticker
SEPURA DMR bar code
sticker
1.05
Appendix 3 Material List (Structural Section)
No. Part Number Part Name Quantity
1 7WFP-4002-01A DP770 lens protection film PET; transparent 1
2 7MHP-4002-02A-WC DP770 LCD lens PC+PMMA, transparent 1
3
7GCJ-S4002-J
DP770lens double-sided tape NITTO 57120B
1
4
7MHP-4002-04A-W9
DP770 PTT cover plate PC+ABS/TPU; black/PT2757C
1
5
7MHR-4002-10A-W6
DP770 side silica gel key silica gel; blue,PT654C;
1
6
7SAF-020070M-SZYB-Z1
2.0X7.0 cross machine screw with iron hardened; black-zinc-plated
2
7 7MHP-4002-01A-W0 DP770 main unit front shell PC+ABS, black 1
8 6SS1-4002-HL3C Accessory board SMD material 1
9 7MHM-4002-01A-W9 DP770 LCD sponge adhesive; black 1
10 7GCB-S4002-01A DP770 speaker dust-proof net; black 1
11 7MHR-4002-16A-W9 DP770 knob waterproof gasket silica gel; black 1
12 4SS7-3525-016-100A DP770 speaker (waterproof ) Φ=35mm,H=25mm,16Ω,1W 1
13
4SM7-4002-A40
Waterproof mic with case Φ7.0mm, height 2.8mm,
1
Page 66 of 102
