Kirisun DP770 Service Manual

DP770 Service Manual
209
5XC1-19R2-TKL3056
B
SMD crystal oscillator
DP770 STP KH620
1 U11
210
1IP1-OMAPL138BZW
T3
Dual core CPU 1 U30
211 1IM1-MT47H64M16 SMD memorizer IC 1 U41
212 1IS1-TC75W51FU R SMD specialized IC 1 U50
213 1IS1-TLV320AIC14K CODEC chip 1 U51
214 1IL1-TDA8547TS E general linear IC 1 U53
215 1ID1-MXD2020ML
SMD general logic IC
（
accelerated sensor
）
1 U62
216 1IS1-XC6209B552MR
SMD voltage regulated
IC
1 U70
217 1IS1-XC6204B502MR
R SMD voltage regulated
IC
1 U100
218 1IS1-XC6204B302MR
SMD voltage regulated
IC
1 U90
219 1IS1-XC6204B332MR
SMD voltage regulated
IC
2 U60,U72
220
1IS1-SKY72310
PLL chip
1
U74
221 1IS1-TLV5614 DA convertor chip 1 U79
222 1TC1-UMC4 R SMD multiunit tube 5 U4,U71,U73,U78,U110
223
1IS1-MC74VHC1GT6
6
High-speed CMOS
simulated switch IC
2 U76,U77
224
1IS1-AD9864
IF digital system
1
U91
225 1IL1-NJM2904V R SMD linear IC 2 U80,U111
226 5XC1-32R8-FC-135
SMD crystal oscillator
STP-U,DP770V
1 X10
227
1IS1-ADE1L
SMD frequency mixer
1
Z10
228
5FC1-DSF51R6M-07
05
R SMD crystal filter,
PT568/78/72/62/65/68/D
R55/DM58/3208/V68/E6
1 Z11
Page 65 of 102
