DP770 Service Manual
6. Tune Mode
It may need to check and adjust the parameters after parts replacement in maintenance.
6.1. Required parts in adjustment
（1）Antenna adapter
（2）Universal interface
6.2. Adjusting and checking method
6.2.1. Frequency description
Model 400~470MHz
Channel
Low
Frequency
Mid-frequen
cy
High
frequency
F1 F2 F3 F4 F5 F6 F7 F8
TX frequency（MHz） 400.00 435.00 470 400 410 420 430 440 450 460 470
RX frequency（MHz） 400.05 435.05 469.95 400.05 410.05 420.05 430.05 440.05 450.05 460.05 469.95
Model 136~174MHz
Channel
Low
Frequency
Mid-frequen
cy
High
frequency
F1 F2 F3 F4 F5 F6 F7 F8
TX frequency（MHz） 136.00 158.00 174.00 136.00 140.00 146.00 152.00 158.00 164.00 170.00 173.975
RX frequency（MHz） 136.05 158.05 174.00 135.05 140.05 146.05 152.05 158.05 164.05 170.05 174.00
