Kirisun DP770 Service Manual

DP770 Service Manual
14 4SM7-4002-A40 Channel switch RE11 1
15
7MHR-4002-09A-W9
DP770 digital key silica gel; PT432C
1
16
7MHS-4002-01A-W
DP770 LCD bracket
1
17
7MHC-4002-11A-W
DP770 display shielding cover 44.3*34.1*2.0MM,copper-nickel
1
18 4PC7-4002H-A LCD screen ZYW-T18CP-20PJ-B 1
19 7MHS-4002-03A-W Digital key METAL DOME diameter is 4.0;SUS301 1
20 6PM7-4002-HKG DP770KEY-LCD PCB board four-layer board 1
21 7SMF-020040M-SZYB-N M2*4 cross machine screw with iron hardened 7
22 7GCM-180090015-J DP770 mainboard double-sided adhesive foam18*9*1.5 1
23 7GCM-100090015-J LCD socket double-sided adhesive foam 10*9*1.5 2
24
7SMF-026060M-SZHT-B1
M2.6*6 cross machine with iron hardened, black-zinc machine
2
25
6SS3-BJ4026-A
KBJ-15belt clip PC+ABS
1
26
7MHR-4002-11A-W9
DP770 main water-proof ring silica gel; black
1
27
7MHP-4002-06A-W9A
DP770 battery top shell PC+ABS; black
1
28 7MHM-4002-02-W Aluminum shell Poron Poron 36.5*2.5*1.0 1
29 7SAF-020110M-SZYB-Z1 2.0X11.0 cross machine screw 5.3 hardened iron; black-zinc-plated 2
30 7MHR-4002-19A-W9 DP770 screw water-proof ring rubber; black; polished 4
31 7GCB-070045005-J Radio Φ7 speaker cloth water-proof film 2
32 7MHP-4002-05A-W9 DP770 main unit top cover PC+ABS; black 1
33 6PD7-4002-DPD1 DP770 battery charging PCB double board 1
34
7MHS-4002-06-N
DP770 battery latch spring steel; nickel-plated
2
35
7MHP-4002-08A-W9A
DP770 open latch PC+ABS/stainless steel; black
1
36
7MHL-4002-01-W
DP770 aluminum shell ADC12;
1
37
7MHR-7042-06B-W0
Silica gel of thermally conductive silica gel gasket; black ,3*6*9mm,
1
38
3CR7-SMA-50JF-4
RF coaxial connector SMA-J, flange plate installation
1
39 7MHR-4002-15A-W9 DP770 antenna water-proof gasket silica gel; black 1
40 4MV3-KFF081522 φ8 DC vibrating motor KFF081522, 1
41 7MHR-4002-17A-W9 DP770 silica gel of motor silica gel gasket; black; 1
42 7MHS-4002-02A-W DP770 motor presser stainless steel; original color; pb-free 1
43 6BPM-933948-074200-B li-polymer battery7.4V,2100mAh 1
Page 67 of 102
