Kirisun DP770 Service Manual

DP770 Service Manual
44 7MHP-4002-07A-W9 DP770 battery bottom cover PC+ABS; black 1
45
7MHR-4002-18A-W9
DP770 discharging base silica gel; black
1
46
7MHP-4002-01A-W
TD7700 battery connector BC-2P-41PH-6.8H
1
47
7MHC-4002-02A-W
DP770 shielding cover bracket 1; 43.4*32.3mm; copper-nickel
1
48 7MBM-S4002-A Conductive foam 12*7*7; with double-sided adhesive 3
49 7MHC-4002-16A-W1 GPS shielding cover base 1; copper-nickel; pb-free 1
50 7MHC-4002-04A-W DP770 shielding cover bracket 2; 22.8*15.6mm; copper-nickel 1
51 6PM7-4002-HMH DP770-02 mainboard PCB ten-layer board 1
52 7SMF-020050M-MHHT-N1 M2*5 torx machine screw with iron hardened, nickel-plated 10
53 6PD7-4002-HPC DP770 PTT board PCB double-sided board 1
54
7MHS-4002-04A-W
DP770 PTT key METAL DOME4.0;SUS301
1
55
7MHS-4002-05A-W
DP770 socket presser stainless steel
，
0.6mm
，
1
56
7MDZ-1737-04A-J5
KB-58L sticker 1 barley paper, 8*35*0.2
1
57
6SS1-4002-HL1G
Main flex cable board
1
58 7MHC-4002-05A-W DP770 shielding cover 2; 23.3*16.1mm; copper-nickel 1
59 7MHC-4002-17A-W1 GPS shielding cover 1 ; copper-nickel; pb-free 1
60 7MHC-4002-03A-W DP770 shielding cover 1 ;43.9*32.8mm; copper-nickel 1
61 7MHJ-4002-01A-W GPS shielding cover conductive cloth; 46.85x32.25x0.15mm 1
62 8ATX-400470-WC DP770 antenna 400-470MHZGPS 1
63 7MHP-4002-03A-W9 DP770 knob PC+ABS/TPU, grey 1
64
7MHS-1767-02B-W
PT6800 knob circlip stainless steel SUS304-1/2H, hardened
1
65
7NRC-077107040-Z
R 7200 channel switch nut brass; black-zinc-plated
1
66
7MHR-4002-13A-WC
DP770 guide beam silica gel; transparent
1
67
7NRC-090110025-W1
Antenna nut
1
68
7MHR-4002-12A-W3
DP770 emergency key silica gel; orange, PT021C
1
