Kirisun DP770 Service Manual

DP770 Service Manual
37 1TF1-RD07MUS2B E R SMD FET 1 Q304
38 1TF1-ST2301 R SMD FET 4 Q905,Q907,Q908,Q901
39 1TT1-2SC3356-R24 R SMD triode 4
Q103,Q104，Q302,Q305
40 1TT1-2SC4617-R R SMD triode 3 Q102,Q105,Q107
41
1TT1-2SC5006
SMD triode
6
Q201,Q203,Q204,Q206,Q207,Q301
42 1TT1-AT41511 Low Noise NPN triode 1 Q205
43 1TT1-DTC144EE R SMD triode 8 Q903,Q1,Q801,Q805,Q30,Q202,Q306,Q309
44 1TT1-FMMT717TA R SMD triode 2 Q106,Q307
45
1TT1-FMMT720
SMD triode
1
Q906
46 1TT1-MMBT3904 SMD triode 1 Q904
47
2CC1-10-C0G500-10
0D
R flake multi-layer capacitor 30
C903,C925,C928,C932,C935,C938,C941,C956,C959,C962,C965
,C968,C971,C974,C977,C980,C981,C987,C990,C993,C996,C99
9,C1002,C1006,C1008,C1012,C1015,C1017,C1020,C1023
48
2CC1-10-C0G500-10
1J
R flake multi-layer capacitor 71
C110,C141,C201,C202,C203,C204,C205,C222,C223,C227,C229
,C244,C909,C926,C929,C931,C934,C937,C940,C955,C958,C96
3,C966,C969,C973,C975,C978,C988,C992,C994,C997,C1001,C
1004,C1005,
49
2CC1-10-C0G500-12
0J
R flake multi-layer capacitor 6 C215,C216,C305,C311,C312,C356
50
2CC1-10-C0G500-15
0J
R flake multi-layer capacitor 2 C245,C246
51
2CC1-10-C0G500-15
1J
R flake multi-layer capacitor 24
C116,C123,C139,C148,C157,C158，C159,C162,C163，
C164,C166,C168,C177,C178,C257,C258,C260,C262,C302,C309
,C315,C321,C327,C346
52
2CC1-10-C0G500-18
1J
R flake multi-layer capacitor 1 C221
53
2CC1-10-C0G500-1R
0C
R flake multi-layer capacitor 7 C118,C150,C301,C945,C947,C949,C952
Page 38 of 102
