Kirisun DP770 Service Manual

DP770 Service Manual
107
2CC1-16-C0G500-6R
0C
R flake multi-layer capacitor 2 C161,C144
108
2CC1-16-C0G500-R5
0B
R flake multi-layer capacitor 1 C336
109
2CC1-16-X7R6R3-10
6K
SMD ceramic capacitor 7 C702,C804,C805,C821,C826,C809,C37
110
2CC1-16-Y5V100-22
5Z
flake multi-layer capacitor 1 C921
111
2CC1-16-Y5V160-10
5Z
R flake multi-layer capacitor 6 C323,C801,C806,C820,C907,C919
112
2CC1-20-Y5V160-10
6Z
flake multi-layer capacitor 3 C915,C917,C923
113
2CC1-32-X5R100-47
6K
SMD flake multi-layer capacitor 10
C101,C102,C105,C106,C241,C242,C352,C902,C904，C2
114
2CT1-TP20-100-100
M
R SMD tantalum capacitor 2
C911，C143
115
2CT1-TS32-100-220
M
SMD tantalum capacitor 3
C1,C830，C913
116
2CT1-TS32-100-4R7
M
R SMD tantalum capacitor 1 C839
117
2CT1-TS32-160-100
M
R SMD tantalum capacitor 11
C103,C104,C108,C109,C172,C180,C181，C182，C183，
C184,C360
118 2CT1-TS32-250-2R2 SMD tantalum capacitor 2 C127,C138
