Kirisun DP770 Service Manual

DP770 Service Manual
140
2LW1-16UC-R33G
SMD coil inductance
7
L104,L105,L107,L110,L111,L114,L217
141 2LW1-20UC-120GA SMD coil inductance 1 L103
142 2LW1-20UC-221J R SMD coil inductance 1 L316
143 2LW1-20UC-331J SMD coil inductance 1 L201
144
2LW1-20UC-8R2J
SMD coil inductance
1
L113
145 2LW1-25UC-103J R SMD coil inductance 2 L202,L203
146 2LW1-25UC-332K SMD coil inductance 1 L205
147 2RE1-10-1003 SMD precision resistor 26
R31,R32,R830,R822,R706，
R133,R134,R138,R207,R222,R223,R228,R229,R316,R317,R334
,R339,R37,R38,R626,R628,R635,R705,R711,R722,R928
148
2RE1-10-2003
SMD precision resistor
1
R702
149 2RS1-10-000O R flake resistor 51
R30,R812,R710,R721,R725,R802,R803,R805,R814,R815，
R816,R869,R926,R927,R40,R41,R115,R116,R119,R123,R144,R
146,R151,R152，R153,R156,R161,R164,R179,R183,R184，
R185,R197,R198,R199,R206,R217,R241，R242,
150 2RS1-10-100J R flake resistor 3 R826,R868,R911
151 2RS1-10-101J R flake resistor 21
R117,R118,R120,R129,R224,R253,R268,R271,R272,R274,R277
,R286,R290,R293,R294,R296,R304,R810,R819,R829,R901
152 2RS1-10-102J R flake resistor 13
R158,R159,R203,R205,R208,R341,R17,R39,R624,R625,R627,R
634,R905
153 2RS1-10-103J R flake resistor 48
R823,R827,R33,R34,C231,R121,R124,R127,R128,R139,R142,R
147,R148,R204,R209,R210,R225,R243,R325,R813,R817,R825,
R916,R917，R918，R919，R920，R921,R923,R924，
R925,R929,R9,R141,R187,R188，R189，
R190,R263,R264,R269,R270,R276,R321,R910,R912,R915,R922
154 2RS1-10-105J R flake resistor 2 R715,R718
155
2RS1-10-121J
R flake resistor
3
R114,R135,R136
156 2RS1-10-123J R flake resistor 2
R130，R907
