Kirisun DP770 Service Manual

DP770 Service Manual
GQ12
218
5XT1-MC146-32R76
K
E SMD
Ceramic Resonator 1 X503
219 6BLS-4814-03327U
SMD button battery (DP770，DM890
，
PT7800,219,620D)
1 BT1
220 7MHP-4002-01A-W TD7700 battery connector 1 J901
221
2CC1-16-C0G500-10
1J
R flake multi-layer capacitor 1 C26
222 2RS1-16-222J R flake resistor 1 FB920
223 2LL1-16-2N2S R Laminated inductance 2 L1,L3
224
2CC1-10-C0G500-2R
5B
R flake multi-layer capacitor 2 C1134,C1153
225
2CC1-10-C0G500-2R
0B
flake multi-layer capacitor 2 C1132,C1143
226 1DR1-BAT54C SMD schottky diode 1 D17
227 1TF1-BSH203 SMD FET 1 Q2
228 1MR1-MC-1010B
GPS/BEIDOU dual module (DP770
780 DM880)
1 U4
229 1IS1-SKY65709-81
GPS front end module pack DP770
DP780
1 U8
230 7MHC-4002-02A-W DP770 shield cover bracket1 1 S2
231 7MHC-4002-04A-W DP770 shield cover bracket2 1 S3
232 7MHC-4002-16A-W1 GPS shield cover base 1 S4
234
1IS1-XC6228D122V
R
SMD Specialized IC 1 U6
235
2CC1-32-Y5V100-22
6Z
flake multi-layer capacitor 4 C905,C914,C918,C922
236
2CC1-10-C0G500-5R
0C
R flake multi-layer capacitor 1 C7
237 2CC1-10-X7R500-18 flake multi-layer capacitor 1 C343
Page 50 of 102
