Kirisun DP770 Service Manual

DP770 Service Manual
257
1DR1-MM3Z12VT1G
Antistatic zener diode
5
D1,D5,D6,D29,D30
258 1DR1-ESD9B5 TVS diode 13 D3,D4,D7,D8,D9,D10,D11,D12,D13,D14,D15,D27,D28
259
5FE1-BLM15BB121S
N1
SMD EMI suppression filter 7 FB1,FB6,FB69,FB70,FB71,FB72,FB73
260
3CB1-7650-20
Female socket
2
J1,J3
261 4PE1-16-F9 SMD LED 8 LED1,LED2,LED3,LED4,LED5,LED6,LED9,LED10
262 4PE1-06-F5 SMD LED 1 LED7
263 4PE1-06-F2 SMD LED 1 LED8
264
3ST1-SKRTLBE010
R SMD touch switch
1
P1
265 1TT1-FMMT717TA R SMD triode 1 Q1
266 1TT1-DTC144EE R SMD triode 3 Q2,Q3,Q4
267
1TF1-ST2301
R SMD FET
1
Q6
268 2RS1-10-471J R flake resistor 1 R2
269 2RS1-10-472J R flake resistor 2 R4,R5
270 2RS1-10-104J R flake resistor 2 R11,R58
271 2RS1-10-331J R flake resistor 8
R13,R14,R16,R17,R18,R19,R61
，
R62
272
2RS1-10-102J
R flake resistor
5
R22,R24,R25,R1,R3
273 2RS1-10-000O R flake resistor 6 R59,R60,R65,R66,R551,R552
274 2RS1-10-272J R flake resistor 1 R67
275 2RS1-10-103J R flake resistor 4 R547,R548,R549,R550
276
3CB1-DF23C-50DP
SMD board-to-board connector
1
U3
277 1IM1-TCA8418 I2C control keypad scan IC 1 U926
278 6PM7-4002-HKG DP770KEY-LCD PCB board 1
279
3FW1-0603L025
Fuse
1
F901
280
2CC1-10-X5R6R3-22
5K
R flake multi-layer capacitor 4 C439 ,C440,C441,C438
281 2RS1-10-4R7J R flake resistor 1 FB5
282
6SS1-4002-HL1G
DP770 main ribbon cable SMD suite
1
283 0SS1-4002-HL1G
DP770
main ribbon cable SMD
unites
1
