Kirisun DP770 Service Manual

DP770 Service Manual
inductance
118
2LW1-20UC-102J
SMD coil inductance
1
L78
119
2LH1-R401R2-L03-05
SMD air-core inductance
1
L79
120 2LH1-R301R0-L04-05
R SMD air-core
inductance
1 L80
121 2LH1-R301R2-L05-05
R SMD air-core
inductance
1 L81
122 2LH1-R301R0-L07-05
R SMD air-core
inductance
1 L82
123
2LH1-R401R5-L07-05
R SMD air-core loop
1
L83
124 2LH1-R301R0-L08-05
R SMD air-core
inductance
1 L85
125
2RS1-20-103J
Flake resistor
1
L86
126
4PE1-06-F2
SMD LED
1
LED10
127 1TF1-ST2301 R SMD FET 5 Q1,Q5,Q12,Q20,Q21
128 1TF1-2SK1824
R SMD FET (production
halt)
2 Q2,Q15
129
1TT1-DTC144EE
R SMD triode
8
Q3,Q8,Q11,Q13,Q14,Q30,Q52,Q71
130
1TT1-MMBT3904
SMD triode
3
Q4,Q6,Q7
131 1TT1-2SC5006
SMD triode (production
halt)
5 Q9,Q51,Q61,Q63,Q64
132
1TT1-FMMT717TA
R SMD triode
2
Q40,Q70
133
1TT1-2SC4617-R
R SMD triode
3
Q41,Q42,Q50
134 1TT1-2SC3356-R24
R SMD triode (production
halt)
3 Q43,Q44,Q72
135
1TT1-2SC5108-Y
R SMD triode
1
Q60
136
1TT1-AT41511
Low noise NPN triode
1
Q62
137 1TT1-2SC3357
R SMD FET (production
halt)
1 Q73
138 1TF1-RD07MUS2B
E R SMD FET
（
S
1 Q74
Page 61 of 102
