Kirisun DP770 Service Manual

DP770 Service Manual
connector
92
3CM1-TFC-008-J
Flap TF clutch base
1
J10
93 3CB1-DF23C-50DS
SMD board-to-board
connector DP770 DP780
1 J20
94
3CC1-USB-UH51543-
CS7
USB port AB-type socket 1 J22
95
2LL1-30-VLS3012T10
0M
Laminated inductance 4 L1,L2,L3,L4
96
2LW1-16UC-R33G
SMD coil inductance
8
L20,L21,L25,L28,L29,L33,L69,L67
97
2RS1-16-000O
R flake resistor
3
L65,L66,R268
98 2LW1-16UC-390G SMD coil inductance 2 L9,L52
99 2LL1-16-3N9S R laminated inductance 2 L15,L16
100 2LW1-16UC-102J SMD coil inductance 3 L22,L30,L64
101 2LW1-20UC-560GB SMD coil inductance 2 L23,L31
102 2LW1-20UC-470GA R SMD coil inductance 1 L32
103
2LW1-32UC-390J
R SMD coil inductance
1
L24
104
2LW1-16UC-180G
SMD coil inductance
1
L26
105
2LW1-16UC-270G
SMD coil inductance
4
L27,L73,L87,L56
106
2LW1-20UC-331J
SMD coil inductance
1
L40
107 2LW1-25UC-103J R SMD coil inductance 2 L41,L42
108 2LL1-16-3R3K R laminated inductance 1 L43
109 2LW1-25UC-332K SMD coil inductance 1 L44
110 2LW1-16UC-560G SMD coil inductance 1 L50
111 2LW1-16UC-680G SMD coil inductance 4 L51,L71,L59,L72
112 2LW1-16UC-181J SMD coil inductance 1 L54
113
2LW1-16UC-330G
SMD coil inductance
2
L57,L53
114
2LW1-20UC-270G
R SMD coil inductance
4
L58,L60,L62,L61
115
2RS1-16-331J
R flake resistor
2
L68,R425
116
2LW1-25UC-102JA
R SMD coil inductance
1
L76
117 2LH1-R401R5-L08-05 R SMD air-core 2 L77,L84
