Kirisun DP990 Service Manual

DP990/DP995service manual
41
91
2LW1-3315-4R7K
SMD wire wound inductor
PCS
L101,L102,L103
3
92
2LW1-16UC-6R8C
SMD wire wound inductor
PCS
L900,L901
2
93
2LW1-16UC-3R9C
SMD wire wound inductor
PCS
L902,L903
2
94
2LW1-16UC-150G
SMD wire wound inductor
PCS
L1007,L1226
2
95
2LW1-16UC-331G
SMD wire wound inductor
PCS
L1001,L1002,L1006,L1008,L100
9,L1010,L1013,L1206,L1210
9
96
2LW1-16UC-181J
SMD wire wound inductor
PCS
L1003,L1227
2
97
2LW1-16UC-470G
SMD wire wound inductor
PCS
L1004
1
98
2LW1-20UC-180J
SMD wire wound inductor
PCS
L1005
1
99
2LW1-16UC-330G
SMD wire wound inductor
PCS
L1011
1
100
2LW1-20UC-120GA
SMD wire wound inductor
PCS
L1012
1
101
2LL1-16-39NJA
Multi-layer chip inductor
PCS
L1200
1
102
2LL1-16-1R0KB
Multi-layer chip inductor
PCS
L1201
1
103
2LW1-16UC-120GB
SMD wire wound inductor
PCS
L1202,L1203,L1224,L1403
4
104
2LL1-16-R27JA
Multi-layer chip inductor
PCS
L1207
1
105
2LL1-16-R10JB
Multi-layer chip inductor
PCS
L1209
1
106
2LL1-16-5N6SA
Multi-layer chip inductor
PCS
L1211
1
107
2LL1-16-47NJC
Multi-layer chip inductor
PCS
L1212
1
108
2LH1-R401R5-R04-05
SMD air core inductor
PCS
L1213,L1214,L1215,L1216,L141
0,L1415
6
109
2LW1-16UC-100GA
SMD wire wound inductor
PCS
L1217,L1225
2
110
2LW1-16UC-220GC
SMD wire wound inductor
PCS
L1218,L1400,L1401,L1402
4
111
2LW1-20UC-331J
SMD wire wound inductor
PCS
L1219
1
112
112L05000003
Wire wound inductor
PCS
L1220,L1221
2
113
2LL1-16-3R3KA
Multi-layer chip inductor
PCS
L1222
1
114
2LW1-25UC-332K
SMD wire wound inductor
PCS
L1223
1
115
2LH1-R401R5-R08-05
SMD air core inductor
PCS
L1405
1
116
2LL1-16-68NJB
Multi-layer chip inductor
PCS
L1406
1
117
2LW1-20UC-8R2J
SMD wire wound inductor
PCS
L1407
1
118
2LW1-20UC-221J
SMD wire wound inductor
PCS
L1408
1
119
2LH1-R401R5-R03-05
SMD air core inductor
PCS
L1409
1
120
2LW1-25UC-100JA
SMD wire wound inductor
PCS
L1411
1
121
2RS1-16-560J
Chip resistor
PCS
L1412
1
122
2LH1-R401R5-R02-05
SMD air core inductor
PCS
L1413
1
123
2LL1-16-3N3SA
Multi-layer chip inductor
PCS
L1414
1
124
1TF1-ST2301
SMD field effect transistor
PCS
Q100,Q601
2
125
1TF1-SSM3K15AFS
SMD field effect transistor
PCS
Q101,Q804
2
126
1TT1-DTC144EE
SMD transistor
PCS
Q102,Q602,Q801,Q802,Q803,Q1
400,Q1,Q312,Q199
9
127
121T03000001
Field effect transistor
PCS
Q600
1
128
1TT1-2SC4617-R
SMD transistor
PCS
Q1000,Q1206
2
129
1TT1-BFU550A
RF triode
PCS
Q1001,Q1002,Q1205,Q1403,Q14
04
5
130
1TT1-2SC5086
Patch triode
PCS
Q1200,Q1202,Q1203,Q1207,Q14
05
5
