Kirisun DP990 Service Manual

DP990/DP995service manual
21
46
7MHR-4072-04A-W0
Top waterproof pad, silicone rubber/stainless steel,black
1
47
7MHS-4072-01A-W
STP press plate of alarm key, stainless steel, original color
1
48
7MHP-4072-04A-W0
PVC pad, transparent, Φ5.0mm*2.0mm*0.3mm
1
49
7GCM-020015010
Sponge mat, EVA, black, adhesive, 1.0mm thick
2
50
7MBP-4072-05B-W0
Auxiliary cover board (reinforced rib), PC+silicon rubber, black, etched
1
51
7MHS-4072-01A-W0
Screw for auxiliary, stainless steel, black, black zinc plated
1
52
7MHF-4072-01A-W
Cover for auxiliary PCB, black, screen print, transparent, one-side
adhesive
1
53
6SS1-4072-HL1A
Auxiliary board SMD nesting
1
54
7MHJ-4072-01A-W
Dual-side waterproof adhesive for auxiliary PCB
1
55
6SS1-4188-HLA
SMD auxiliary FPC board
1
56
157F15000043
EVA R rubber pad, black,E132:E135 adhesive, 10.0*9.0*2.0mm
1
57
7MHB-4334-01A-W0
Conductive cloth for front shielding cover , 40.5*19.5*0.1mm
1
58
157F15000069
Highland barley paper, 24*8*0.2mm, 0.2mm thick, single-side adhesive
1
59
7MHC-4072-01A-W
Knob nut, brass,inner diameter 6 mm, outer diameter 9 mm, 2.4mm thick
2
60
7MBR-4182-01A-WC
Light pipe, silicon rubber, transparent
1
61
7MHS-4072-08A-W
Knob circlip, stainless steel, T=0.3, original color
2
62
147K01000052
Volume knob, black, etched, white oil brushed
1
63
147K01000051
Coding knob, black, etched, white oil brushed
1
64
7MHR-4182-01A-W3
Alarm key, silicon rubber, PT 172C
1
65
3CR7-S4182-A
RF coaxial connector, brass, 1/4-36, gold plated, lead free
1
66
7MHR-4182-04A-W0
Waterproof pad for antenna connector
1
67
7NRC-090115025-W1
Antenna connector nut
1
68
8ATX-151162-WE
8ATX-151162-WD
8ATX-162174-WD
8ATX010006
Antenna,151-162MHz, with GLONASS/GPS;
Dual-mode rubber antenna (with GPS/BD), 147mm long;
Dual-mode rubber antenna, 162-174 MHZ, with GPS/BD, 135mm long;
Antenna, GPS/BD, 400~480 MHz, 99±2mm
1
