Kirisun DP990 Service Manual

DP990/DP995service manual
20
13
4SM7-4002-A44
Waterproof microphone (with case)
1
14
157F15000087
Dual-side adhesive, black, Φ39.8*36*0.2
1
15
4SS7-4072-016-015C
Waterproof speaker, IP68, Φ40, H=5±0.3mm, 16Ω, 1.5W
1
16
7MHC-4182-02A-W
Speaker holder, 0.7mm thick, stainless steel, natural color
1
17
147K04000020
Master waterproof ring, silica rubber, orange, high elasticity
1
18
62DI000106
LCD board/panel
1
19
6SS1-4127-HK1A
Main FPC nesting
1
20
157F15000086
Sponge mat, black
3
21
7GGM-4073-03A-W
Sponge mat, EVA, black, adhesive, 12x7x3
1
22
7MDZ-7050-01A-J5
Insulative paper, highland barley paper, 18mm*15mm*0.2mm (L*W*H)
1
23
7SMF-020040M-SZYB-N
Cross recessed mushroom-head machine screw, nickel plated, metric
coarse thread, Φ2mm*4mm
11
24
3SE3-RE08110NX-V02B
Stepless channel encoder, IP68
1
25
2RW3-RP08110SNJX-V2B
Potentiometer switch, IP68
1
26
7MJS-4142-02A-W0
F9 PTT key spindle, stainless steel, original color, SUS304
1
27
7PLP-4182-01A-W0
Sticker for TF card holder, PVC
1
28
7MHR-4182-05D-W0
Waterproof silicon rubber cover for TF card (wire drawing), stainless
steel and silicon rubber, orange
1
29
6SS1-4127-HK2B
Past mask nesting for encryption board
1
30
7SMF-014030M-SZCT-N
Cross recessed countersunk-head machine screw, low-carbon steel,
nickel plated
1
31
7MHR-4072-06A-W0
O-shaped ring, silicon rubber, outer diameter 4 mm, wire diameter 1.0
mm
6.5
32
147K03000008
Aluminum housing, original color, ground, sand blast and electroplanted
surface
1
33
7SMS-025075M-SZYB-N1
Torx round-head machine screw, stainless steel, M2.5*7.5
4
34
157F15000083
Waterproof breathable membrane, White, φ7.1*φ5.3*0.3mm, IP68
1
35
7SMS-025270M-SZYB-N1
Torx round-head machine screw, nickel plated
2
36
6SS3-BJ4188-A
KBJ-19 belt clip, black
1
37
7SMF-025080M-SZYB-Z
Cross round-and-mushroom headed machine screw, black zinc plated,
Φ2.5mm*8mm
2
38
7MBP-4072-04A-W0
Top housing, black, etched
1
39
7MHR-4182-03A-W0
Heat-conducting silicon-rubber pad, black, 30*8*0.5mm
1
40
7MHR-4182-01A-W0
Discharge waterproof pad, hardness 30°, silicon rubber, orange PT172C
1
41
4MV3-KFF081522
DC vibration motor
1
42
7MHR-4072-09A-W0
Motor case, silicon rubber, yellow
1
43
7MHS-4072-02A-W
STP press plate of motor, stainless steel, original color
1
44
62DI000215
62DI000194
Mainboard DP990-02, 400~470 MHz, GPS/BDS, Man down, 4W,
hardware V2.0;
Mainboard DP990-01, self-locking, crystal compatible, overdischarge
protection
1
45
7MHP-4072-03A-W0
Pad for coding/volume knob, PET, 23*9.5*0.4mm
1
