Kirisun DP990 Service Manual

DP990/DP995service manual
61
inductor
125
112L01000014
Air-core inductor
PCS
L2313,L2314,L2315
3
126
2LH1-R401R5-L07-05
SMD air core coil
PCS
L2319
1
127
2LW1-16UC-120G
SMD wire wound
inductor
PCS
L2316
1
128
2LW1-16UC-330G
SMD wire wound
inductor
PCS
L2402,L2403
2
129
2RS1-20-103J
Chip resistor
PCS
L2318
1
130
2LW1-20UC-470GA
SMD wire wound
inductor
PCS
L2320
1
131
2LW1-16UC-390G
SMD wire wound
inductor
PCS
L2321,L2407
2
132
2LW1-16UC-271G
SMD wire wound
inductor
PCS
L2401
1
133
2LW1-16UC-181J
SMD wire wound
inductor
PCS
L2404
1
134
2LW1-20UC-270G
SMD wire wound
inductor
PCS
L2406,L2408,L2409,L2410
4
135
2LW1-16UC-R33G
SMD wire wound
inductor
PCS
L2418
1
136
2RE1-16-3300
Precise SMD resistor
PCS
L2417
1
137
1TF1-ST2301
SMD field effect
transistor
PCS
Q100,Q601
2
138
1TF1-SSM3K15AFS
SMD field effect
transistor
PCS
Q101,Q804
2
139
1TT1-DTC144EE
SMD transistor
PCS
Q102,Q602,Q801,Q802,Q803
,Q2300,Q1,Q199
8
140
121T03000001
Field effect transistor
PCS
Q600,Q800
2
141
1TT1-2SC4617-R
SMD transistor
PCS
Q1000,Q1206
2
142
1TT1-BFU550A
RF triode
PCS
Q1001,Q1002,Q2301,Q2303,
Q2402
5
143
1TT1-2SC5086
Patch triode
PCS
Q1207,Q2302,Q2400,Q2401,
Q2403,Q2404
6
144
1TF1-RD01MUS2-501
SMD field effect
transistor (for portable
digital and analog
radios)
PCS
Q2304
1
145
1TF1-RD07MUS2B-501
ER SMD field effect
transistor
PCS
Q2305
1
146
2RE1-06-2002
Precise SMD resistor
PCS
R4,R1232,R601,R1064
4
147
2RS1-16-100J
Chip resistor
PCS
R2,R1240,R1246,R1007,R10
23
5
148
2RE1-06-1003
Precision resistor
PCS
R607,R608
2
149
2RS1-10-474J
Chip resistor
PCS
R101
1
150
2RS1-10-103J
Chip resistor
PCS
R102,R203,R208,R209,R202,
R110
6
151
2RS1-06-470J
Chip resistor
PCS
R103,R2400,R2401,R2303
4
152
2RE1-10-1003
Precise SMD resistor
PCS
R104,R106,R2307,R2319
4
153
2RE1-10-1802
Precise SMD resistor
PCS
R105
1
154
2RS1-10-000O
Chip resistor
PCS
R107,R144,R145,R807,R813,
10
