CHAPTER 2: SPECIFICATIONS
This chapter includes the physical and performance specifications for the main
components of the Series 5000 V2 Sonar System.
2.1 Sonar System
Beams: 5 port and 5 starboard
Sonar frequency: 455 kHz
Maximum range: Up to 150 m per side (actual range varies
with environmental conditions and pulse
length)
Range scales: 50, 75, 100, and 150 m; 50 and 75 m are
high resolution; 200 and 250 m
reconnaissance mode
Swath width: 100 to 500 m (usable swath width varies
with environmental conditions and pulse
length)
Along track resolution: 10 cm @ 38 m, 20 cm @ 75 m and
36 cm @ 150 m
Across track resolution: 3.75 cm
Operating speed envelope: 2 to 10 knots at 150 m
Depth rating: 500 m (1640 ft)
200 m (656 ft) with bathymetry option
Operating temperature: -2–35C (14–95F)
NOTE Specifications are typical and subject to change without notice.
