Klein 5000 V2 Series - Figure 3-1: TPU Back Panel

Topside System Connections 3-7
Figure 3-1: TPU Back Panel
TOWFISH connector
NOTE: Connectors that are not
called out are not used or are
for factory use only.
NAV connector
AC INPUT connector
1 PPS IN connector
T/F TRIG connector
TRIG A connector
LAN connector
