Klein 5000 V2 Series - Figure 3-2: Sonarpro Workstation Back Panel

Topside System Connections 3-9
Figure 3-2: SonarPro Workstation Back Panel
ON/OFF switch
AC INPUT connector
ETHERNET connector (2)
USB connector (4)
NOTE: Connectors that are not
called out are not used or are
available for optional use.
DVI connector
and circuit breaker
