3-14 CHAPTER 3 Preparation for Use Series 5000 V2 Sonar System Operations and Maintenance Manual P/N 11214512, Rev. 04
Figure 3-4: SonarPro Workstation Front Panel
HARD DRIVE ACTIVITY indicator
POWER ON indicator DVDRW optical drive
ETHERNET indicator
RESET switch
POWER switch
USB connector (2)
