Back of the printer
11
User Guide
Nameplate
USB cable port
Power port
USB-C
(only for programming)
Nameplate
The nameplate which is sticked to
the rear frame of the Klecard contains
the main technical information and the
serial no.
Refer to this serial no for servicing.
S/N is made by 10 digits like this:
18KL-G1120
The rear view show the three ports
of the Klecard.
The left USB port is for the connection to
your pc.
The right one is the port where you
need to connect the cable of the
power supply.
The middle is reserved for programming.
Go to page 13 for connecting cables.
Model: S/N: Year:
Made in EU
100-240 Vac 50/60 Hz 1.3 A
KLECARD xKL-xxxxx 20xx
KIZILÜZÜM MAHALLESİ KEMALPAŞA
KIZILÜZÜM CADDESİ NO:15
35730 KEMALPAŞA İZMİR/TURKIYE
