WARNING



MOVE WET LITTER HOLD DOWN
BLOCKS TO STORAGE POSITION
SHOWN IN DIAGRAM.
AND PLACE BUMP PADS AS
BUMP PADS
DRY LITTER OPERATION
IMPORTANT!
MOVE THE WET LITTER HOLD
WET LITTER OPERATION
(WET LITTER)
WORKING POSITION
IN STORAGE CANNISTER.
LITTER. PLACE BUMP PADS
DOWN BLOCKS INTO THE
REMOVE ALL BUMP PADS
WHEN OPERATING IN WET
WORKING POSITION AND
(DRY LITTER)
STORAGE POSITION
TALL BUMP PADS
IMPORTANT!
GREASE ALL POINTS EVERY 50 HOURS AND BEFORE STORAGE
TONGUE PIVOTS
YOKE
REEL BEARINGS
IDLER SHAFT BEARINGS
The following chart shows locations of bearings which need regular lubrication. We
recommend that all bearings be greased on a weekly basis (every 50 hours of use). If the
use of the machine is going to be less than a week, we recommend that it be greased just
prior to storage.
Lubrication Chart
IDLER SHAFT BEARINGS
DRIVE SHAFT BEARINGS
