15
The tongue of the unit is
designed to pivot from a straight pull
in the center of the machine to an
offset pull to the left of the machine.
This is to facilitate shifting the unit to
the right of the tractor wheels for
cleaning close to the walls inside
the poultry house. Before starting to
clean out a house, you should
decide whether you want to start
next to the walls or in the middle of
the house and set the tongue
accordingly.
SAFETY
LATCH
Always install the safety latch on the tongue cylinder when transporting or working
underneath or around the pickup.
CAUTION
Tongue
Apply grease to the internal splines of the
speed increaser (NLGI no.2, Lithium thickener
based with molybdenum additive.)
Slide the speed increaser onto the PTO shaft
and let torque arm rotate to the right side of the
drawbar.
Attach the chain to the tractor so that it will not
allow the pump to slide backwards more than ¾”.
(If the pump is able to slide off the pto shaft too
much, damage to the pto shaft and internal
splines of the speed increaser can occur.)
Grease Spline
Shaft on PTO on
Tractor Before
Hooking up to Tractor
