30
If it becomes necessary to
tow the PHC behind a truck for
extended distances, the following
adjustments are recommended:
Store the hydraulic pump on the
support pin on the tongue and
secure it with the torque bar chain
as shown. Next, turn the control
valve ninety degrees from the
direction of travel and pin the
position as shown.
Put the transport lock in
position on the tongue cylinder
ram. Tie up all hoses to prevent
them from dragging or getting
pulled off.
Maximum tow speed for
the machine is 25 mph.
Tongue weight for towing is
1,500 lbs.
TRANSPORT
LOCK
Safety chains are available
when transporting the machine from
one field to the next.
TRANSPORTATION
Transport Lock Position
CONTROL
VALVE
HYDRAULIC
PUMP
MOUNTED
Safety Chain
To Next Page
