Kodak Dental Imaging Software Overview
KODAK 9000 3D Extraoral Imaging System_User Guide (SM710)_Ed 01 3–5
Imaging Window Overview
The Imaging Window is the main imaging interface that provides you with the panoramic
imaging functions.
Figure 3–2 Imaging Window
1Title Bar: Displays:
• Software name
• Software version
• Practitioner name
• Patient name
2
Menu Bar: Provides access to the following functions:
3 Toolbar: Provides quick
access to the following
menu functions:
Menu Submenu Description
File New panoramic
Accesses the Panoramic
Acquisition Window for a
panoramic image
New 3D image Accesses the 3D Acquisition
Window for a 3D image
History Open Opens the patient history record with
image files
Save Saves the acquired image
Close Closes the patient image
