3–22 IMAGING SOFTWARE OVERVIEW
3D Patient Pane
The 3D Patient pane enables you to choose different patient parameters. The selection of the
patient parameters influences the quality of the image. The selected parameters must be based
on the patient age and morphology.
Figure 3–13 Panoramic Patient Pane
1 Patient corpulence parameters:
Click if the patient is a child.
Click if the patient is small.
Click if the patient is medium.
Click if the patient is large.
2 Patient dental arch morphology:
Click for a square dental arch.
Click for a normal shape dental arch.
Click for a sharp dental arch.
3
Incisors orientation:
Click for a vestibular orientation.
Click for an axial orientation.
Click for a lingual orientation.
