Acquiring a 3D Image
5–10 ACQUIRING IMAGES
Launching the x-ray
To launch the x-ray, follow these steps:
1. Leave the x-ray room and close the door. You must keep eye contact with the patient
during acquisition.
2. Trigger the x-ray with the remote control. Press and hold the exposure button until the end
of acquisition. The turns yellow indicating x-ray emission. The image appears in the
Preview Screen. When the acquisition ends, the 3D Acquisition Window disappears.
3. Open the 3D head support and release the patient while waiting for the 3D image
reconstruction. Remove the hygiene barrier of the bite block.
4. Wait for the 3D image reconstruction. Open the Imaging Window and
IMPORTANT
To stop the acquisition, if any problem, release the exposure
button of the remote control or press the red emergency stop
button.
