Unit Technical Specifications
7–2 TECHNICAL SPECIFICATIONS
Unit Technical Specifications
Table 8-1 describes the technical specifications for the KODAK 9000 3D digital imaging unit
and Kodak 9000 digital imaging unit.
Table 7–1 Unit Technical Specification
Kodak 9000 3D Kodak 9000
X-Ray Generator
Tube voltage 60 - 90 kV (max), pulsed mode for 3D modality
Tube current 2 - 15 mA (max)
Frequency 140 kHz (max)
Tube focal spot 0.5 mm (IEC 60336)
Total filtration > 2.5 mm eq. Al
3D Modality
Technology Digital Volumetric Tomography (DVT) NA
Sensor technology
• CMOS
• Optical fiber sensor with Csi
coating
NA
Gray scale 16384 - 14 bits NA
Volume size 50 x 37 mm NA
Voxel size 76.5 x 76.5 x 76.5 µm NA
Reconstruction time Depends on the PC NA
X-ray pulse time 30 ms
Panoramic Modality
Sensor technology
• CCD
• Optical fiber sensor with Csi coating
Sensor matrix 61 x 1244 pixels
Image field 6.3 x 129.4 mm
Gray scale 16384 - 14 bits
Magnification 1.27
Exposure time
• Adult panoramic 13.9 sec.
• Pediatric panoramic 13.2 sec.
Programs 12 anatomical settings
Radiological exam options
• Panoramic
• Segmented panoramic
• Maxillary sinus
• LA TMJ x2
• LA TMJ x4
