Kodak Dental Imaging Software Overview
KODAK 9000 3D Extraoral Imaging System_User Guide (SM710)_Ed 01 3–9
To access the 4 View Window, from the Home Page click the 4 View Window tab.
Figure 3–4 4 View Window
1Title Bar: Displays software name and version.
2Window Tabs: Provides access to the indicated windows.
3 Menu bar: provides access to the following functions:
Menu Submenu Description
General Information Displays the 3D image acquisition information
MPR (MultiPlanar
Reformat)
Adjustment Adjusts the slices contrast and brightness
Position Resets the cut planes position
3D Scene Adjusts the 3D view
Cut Planes
Click to show or hide the cut planes.
Click to display the cut plane as images.
Click to display the cut plane as wireframe.
Click to display the cut plane as colored planes.
3D Filters
Click to apply the smooth filter.
Click to configure the smooth filter settings.
