Acquisition Interface Module
3–20 IMAGING SOFTWARE OVERVIEW
The Selector button enables you to access the following 3 panes:
• Program pane: Examination type options
• Patient pane: Patient type parameter options
• Parameters pane: Exposure parameter options
10 Exit button: Closes the Acquisition Window.
11 X-Ray Emission Indicator: Yellow indicates the x-ray emission status.
12 Selector button: Selects different acquisition setting options.
• Click Program to select examination type options
• Click Patient to select patient type parameters
• Click Parameters to select exposure parameter options
