Acquiring a Panoramic, TMJ x2 or Sinus Image
KODAK 9000 3D Extraoral Imaging System_User Guide (SM710)_Ed 01 5–5
2. Launch the x-ray with the remote control. Press and hold the exposure button until the end
of acquisition. The turns yellow indicating x-ray emission. The image appears on the
Preview Screen of the Panoramic Acquisition Window. When the acquisition ends, the
Panoramic Acquisition Window disappears and the acquired image is automatically
transferred to the Imaging Window.
3. Check the image quality.
4. Do the following when the acquisition is finished:
• Open the temple supports and release the patient.
• Remove the hygiene barrier of the bite block.
• Reset the Unit rotative arm for the next acquisition.
