THEORY GUIDE Scan/Erase
10DEC05
TG4825-1
Page
68 of 120
Section 7: Scan/Erase
Overview
The Scan/Erase subsystem moves the PLATE:
• through the field of scan at a uniform speed
• to the ERASE AY to be erased
• back up to be inserted into the CASSETTE SHELL
H194_5047HC
from MCPU BOARD
A1
BOARD
MSC
A6
BOARD
CONTROLLER
SLOW SCAN
PLATE
SHELL and
CASSETTE
EXTRACTION BAR
PLATE POSITIONING AY
ERASE LAMPS
LEAD SCREW
COIL BOARD A7
ENCODER
SLOW SCAN MOTOR
H194_5047HCA
